Machine type | HXE-13DL | HXE-9DL |
Inlet diameter | Φ8 | Φ8 |
outlet diameter | Φ1.2~Φ4.0 | Φ2.2~Φ4.0 |
Max.line speed | 2000 | 1500 |
Dies Number | 13 | 9 |
Elongation coefficient | i=1.4~1.2in descending orderi=1.4~1.2 decreasing | |
Capstan | Tungsten | |
Max capstan diameter | Φ450 | |
Fix speed capstan diameter | Φ450 | |
Frame | Fission casting | |
Main motor | DC250KW | DC200KW |
Fix speed capstan motor | DC75KW | |
Coiler motor | AC15KW | |
Dual spooler | 2×DC30KW | |
Revise system | PID synchronous control spoole | |
Inverter control | 590DC converter | |
Transmission type | Gear | |
Pay-off method | Portal type | |
Traversing unit | Decelerate motor | |
Tension control | Pneumatic balance by swing arm | |
Lubrication type | Full dip-in type | |
Applicable spooler size of Dual spooler | Φ500~Φ630 | |
Coiler capacity (KG) | 1200~1800 | |
Power source (V) | 50HZ/380V | |
Brake | Pneumatic brake | |
Dimension | 26500×6700x5000 | 23800×6700×5000 |
-
