Machine type | HXE-22DW | HXE-24DW |
Inlet diameter(mm) | Φ0.6--Φ1.2 | Φ0.6-Φ1.2 |
outlet diameter (mm) | Φ0.1--Φ0.7 | Φ0.08-Φ0.5 |
Max.line speed (MPM) | 2500 | 2500 |
Die number | 22 | 24 |
slip ratio of machine | 15% | 13% |
Slip ratio of fix speed capstan | 8% | 8% |
Capstan | Ceramic plasma | Ceramic plasma |
Max.capstan diameter(mm) | Φ242 | Φ242 |
Fix speed capstan diameter (mm) | Φ207 | Φ207 |
Frame | Iron cast | Iron cast |
Main motor | 15KW three phase ACmotor | |
Spool motor | 3.7 three phase AC motor | |
Revise system | PID synchronous control spoole | |
Power control | Inverter control | |
Transmission type | Flat belt | |
Pay-off method | Over-head | |
Traversing unit | Flat belt + synchronous motor | |
Tension control | Weight balance by swing arm | |
Lubrication type | Spray type | |
Applicable spooler size | Φ300 | Φ300 |
Spooler capacity | 50-60 | 50-60 |
Bobbin loading&unloading type | Shaft type | |
Power source | 380V | |
Brake | Pneumatic brake |
-
