Super Fine Copper Wire Drawing Machine
  • Super Fine Copper Wire Drawing Machine
  • Super Fine Copper Wire Drawing Machine
  • Super Fine Copper Wire Drawing Machine
  • Super Fine Copper Wire Drawing Machine
  • Super Fine Copper Wire Drawing Machine
  • Super Fine Copper Wire Drawing Machine

Super Fine Copper Wire Drawing Machine

+86-15006209216 Contact Us
A Super Fine Copper Wire Drawing Machine is state-of-the-art equipment designed to transform raw copper into ultra-thin wires with exceptional precision and quality. This machine utilizes a series of drawing dies to reduce the diameter of the copper rod, resulting in wires of various diameters. The process involves pulling the copper rod through these dies, which gradually decrease in size until the desired wire diameter is achieved. The ability to produce wires quickly and efficiently significantly increases production capacity, making it a cost-effective solution for wire manufacturers.
PREV：No previous product
NEXT：No next product
  • Description
  • Machine type HXE-24VX HXE-20D
    Inlet diameter(mm) Φ0.14-Φ0.45 Φ0.15-Φ0.4mm
    Outlet diameter (mm) Φ0.025-Φ0.08 Φ0.05-Φ0.12mm
    Max.line speed (MPM) 1500 1800
    Die number 24 20
    Slip ratio of machine 8% 10.5%
    Slip ratio of fix speed capstan 7% 6%
    Capstan Ceramic plasma Ceramic plasma
    Max.capstan diameter (mm) Φ100 Φ120
    Fix speed capstan diameter(mm) Φ100 Φ120
    Frame Welded by steel plate Iron cast
    Main motor 4KW three phase AC motor 5KW three phase AC motor
    Spool motor 2.2KW three phase AC motor
    Revise system Automatic tension control PID synchronous control spoole
    Power control Inverter control
    Transmission type Flat belt
    Pay-off method Hairbrush Over-head
    Traversing unit Free rod type 50W-100W strap synchronous motor
    Tension control Tension tape wheel device Weight balance type
    Lubrication type Spray type Spray type
    Applicable spooler size (mm) Φ200 Φ250
    Spooler capacity (kg) 10 30
    Bobbin loading&unloading type Shaft type
    Power source 380V
    Brake Magnetic brake
    Dimension 1740L×1300Wx1450H 1900L×1350W×1750H
    Weight 1200kg 1900kg

Related Products

Suzhou Hengxie Machinery Co., Ltd.

We are an enterprise specializing in the research, development, production and sales of cable equipment series products.

Suzhou Hengxie is China Super Fine Copper Wire Drawing Machine Manufacturers. Our main products of company are as following: 9, 13 dies rod breakdown machine and 17 dies medium drawing machine (chain or ground gear transmission type), medium and large drawing machine with continuous annealer, 14 dies medium and fine wire drawing machine, 22 or 24 dies fine wire drawing machine, 20 or 24 dies super fine wire drawing machine, annealing and tinning machine, medium wire drawing machine with double spooler, and hing speed auto stranding machine, etc.Our products include both domestic market and oversea market such as India, Brazil,Egypt, Malaysia, Korea, Vietnam, Syria, Kenya, Argentina, South Africa and Iran. With the concept of stable quality and mutual development, Hengxie welcomes all customers from the world to create a sincere cooperation and win-win benefit in the future.
